The technologies have been upgraded to adapt to the fast-changing needs of the competitive market. As the manufacturing technologies advance, the performance of the finished Ultra Thin Ip67 Waterproof 24w Low Voltage 24vdc Rgb Led Linear Wall Washer For Hotel has been improved a lot.It has an enormous effect on the field(s) of Wall Washers.
Combining the efforts of all our staff and keeping up with the trend, Shenzhen Dinglixiang Electronic Co.,Ltd. has developed the version of Ultra Thin Ip67 Waterproof 24w Low Voltage 24vdc Rgb Led Linear Wall Washer For Hotel . It is borne with the updated features and is expected to create values and benefits for customers. Modern technologies innovate means are adopted for the flawless manufacturing of Ultra Thin Ip67 Waterproof 24w Low Voltage 24vdc Rgb Led Linear Wall Washer For Hotel.So far, the application areas of the product have been expanded to the Wall Washers. To meet various needs of customers, Shenzhen Dinglixiang Electronic Co.,Ltd. supports customized Ultra Thin Ip67 Waterproof 24w Low Voltage 24vdc Rgb Led Linear Wall Washer For Hotel.
| Color Temperature(CCT) | RGB RGBW | Lamp Luminous Efficiency(lm/w) | 80 |
| Color Rendering Index(Ra) | 90 | Support Dimmer | Yes |
| Lighting solutions service | Lighting and circuitry design, DIALux evo layout, LitePro DLX layout, Agi32 layout, auto CAD layout, Onsite metering, Project Installation, Custom on demand | Lifespan (hours) | 50000 |
| Working Time (hours) | 50000 | Product Weight（kg） | 2 |
| Light Source | LED | Item Type | Wall Washers |
| Input Voltage(V) | dc 12v 24v ac 220v 240v meanwell driver | Lamp Luminous Flux(lm) | 80 lumens /w |
| CRI (Ra>) | 75 | Warranty(Year) | 2 years,3 years,5years |
| Working Temperature(℃) | -25 - 50 | Working Lifetime(Hour) | 50000 |
| Lamp Body Material | Aluminum housing n Tempered Glass diffuser | IP Rating | IP65 IP66 IP67 IP68 |
| Place of Origin | Guangdong, China | Brand Name | Yuanyeled |
| Model Number | YY-XQ..W-4057 | Application | outdoor,window,landscape lighting,amusement,architectural,indoor, river bank,facade,garden,backyard,beach,bridges,city night |
| Product Name | low voltage led wall washer | Size | custom Length 300mm - 1500 mm W40mm H57mm |
| wattage | 9w,10w,12w,15w,18w,20w,24w,30w,36w,48w,50w,54w,14x3w | Light source | smd/cob 5050,2835,5630,3528,3030 chip |
| single color | white,green,pink,orange,yellow,amber | multi color | 3in1 3w rgb,4 in 1 rgbw,5in1 rgbwa |
| Installation | floor,wall mounted | dmx 512 signal | addressable n programmable with dmx decoder |
| Control | dmx 512 controller control or wifi/ wireless remote control |
This is 100% factory owned private mold with 6063 Aluminum Housing puls Tempered Glass Cover,beautiful appearance and reasonable waterproof structure,as well as heat-resisting and impact resistance.
This wall washer is suitable for outdoor, indoor use.
The waterproof is IP20,IP65, IP67 and IP68.
• Multiple Power Options - custom watt 1w to 50w
• Input Voltage Options – AC100-240V, AC/DC12V,24V,36V,48V(model with W40*H57mm) ;
AC/DC12V,24V,36V,48V(model with W40*H33mm)
• Light color Option - RGB/RGBW/Single color(Red, blue, green, yellow, pink, purple, white color ...) RGBCCT,RGBWCCT
• Beam angle Option - 5°,8°,10°,15°,30°,45°,60°,90°,120°,10ox15o,10ox35o,10ox45o,10ox50o,10ox60o,30ox65o
• Eco-friendly, UV-Resistant, waterproof IP20,IP65,IP67 and IP68.
• 2 models for options, same width 40mm, custom length 1200mm maximum, hight 57mm or 33mm.
Name | Value | ||||
Reference size and watt (YY-XQ..W-4057 and YY-XQ..W-4033 suitable) | L100mm,2w,3w,4w,5w L150mm,4w,5w, 6w,7w L200mm,6w,7w,8w,9w,10w L250mm,8w,9w,10w,12w L300mm,12w,14w,15w L350mm,12w,14w,15w,16w,17w L400mm,16w,17w,18w,19w,20w L450mm,18w,19w,20w,21w,22w L500mm,18w,19w,20w,21w,22w,23w,24w,25w L550mm,18w,20w,21w,22w,23w,24w,25w,26w,27w L600mm,18w,20w,21w,22w,23w,24w,25w,26w,27w,28w,29w,30w L650mm,18w,20w,21w,22w,23w,24w,25w,26w,27w,28w,29w,30w,31w,32w L700mm,18w,20w,23w,24w,25w,26w,27w,28w,29w,30w,31w,32w,33w,34w,35w L750mm,18w,20w,24w,25w,26w,27w,28w,29w,30w,31w,32w,33w,34w,35w,36w,37w L800mm,18w,20w,24w,25w,27w,28w,29w,30w,31w,32w,34w,35w,36w,37w,39w,40w L850mm,18w,20w,24w,25w,27w,28w,29w,30w,31w,32w,34w,35w,36w,37w,40w,42w L900mm,18w,20w,24w,25w,27w,28w,29w,30w,31w,32w,35w,36w,37w,40w,42w,45w L950mm,18w,20w,24w,25w,27w,28w,29w,30w,31w,32w,35w,36w,40w,42w,45w,47w L1000mm,18w,20w,24w,25w,27w,28w,30w,32w,35w,36w,40w,42w,45w,47w,48w,50w L1200mm,18w,20w,24w,25w,27w,28w,30w,32w,35w,36w,40w,42w,45w,47w,48w,50w | ||||
Width n Height | YY-XQ..W-4057, width 40mm, height 57mm YY-XQ..W-4033, width 40mm, height 33mm | ||||
Material | Aluminum + Tempered Glass | ||||
Light Source | Brand SMD with lifespan 50000 Hours | ||||
CCT | 2200K,2700K,3000K,4000K,4500K,5000K, 6000K,6500K, RED,BLUE, GREEN,YELLOW,AMBER RGB, RGBW, RGBY, RGBCCT,RGBWCCT (CCT: Correlated Color Temperature) | ||||
Waterproof Rate | IP20 IP65 IP67 IP68 | ||||
Input Voltage | YY-XQ..W-4057, AC100-240V, AC/DC12V,24V,36V,48V YY-XQ..W-4033, AC/DC12V,24V,36V,48V | ||||
control/dimming | ON/OFF, DMX512,DALI,0/1-10V, TRIAC,PWM,ZIGBEE... | ||||
Certificate | CE , RoHS | ||||
Package and Logo | Standard Export Carton with Individual pack / PE layer ; Customized packing and Logo is acceptable. | ||||
underwater, wet location, coastal regions...
All our products are CE certified as well as RoHS compliant. Please contact us too if you need UL/CUL.
